ZYXEL Wireless Router LTE B1/3/7/8/20/38/40,WCDMA B1/8, Standard,EU/UK Plug,FCS, support CA
- Gyártó: Zyxel
- Cikkszám: LTE7460-M608-EU01V3F
- Készlet információ: Rendelésre
- Átvétel: érkezés +1 munkanap
121 905 Ft
Bruttó ár: 154 819 Ft
Kívánságlistára
Összehasonlítás
IP Networking
- Support IPv4/IPv6 dual stack (NDP IPv6)
- DHCP Server
- ICMP supported
- Bridge/Router mode supported
- Virtual Private Network (VPN) pass through
Network Address Translation (NAT) Traversal
- Support NAT/NAPT
- Support DMZ
- Support port forwarding
- Support ALG
- Support DDNS
IP Firewall
- DoS Attack Prevention
- Support SPI
- Application-Level Firewall (LAN to WAN such as FTP, HTTP, Telnet, Ping)
Management
- Support Local/Remote Web management and web online firmware upgrade
- Support TR069 and TR069 remote firmware upgrade
- SMS management
- APN/PIN management
- PIN/PUK management
- Network selection
- Network preference
- Operating frequency band selection (support Cat 4 only)
LTE Interface
- Standard compliant: 3GPP Release 10 Category 6
- Supported frequency:
- Band LTE 1/3/7/8/20/38/40
- LTE TDD 2300/2600 MHz
- LTE FDD 2600/2100/1800/900/800 MHz
- Carrier aggregation configuration:
- B1+B3*, B1+B7*
- B1+B1, B1+B8, B1+B20
- B3+B3, B3+B7, B3+B8, B3+B20
- B7+B7, B7+B8, B7+B20
- B38+B38, B40+B40
- FDD LTE peak data rate:
- 300 Mbps DL within 40 MHz bandwidth (CA)
- 50 Mbps UL within 20 MHz bandwidth
- TDD LTE peak data rate:
- 224 Mbps DL within 40 MHz bandwidth (CA)
- 10 Mbps UL within 20 MHz bandwidth)
UMTS/EDGE/GPRS/GSM Air Interface
- Standard compliant: WCDMA Rel’99 and Rel’10 DC-HSPA+; GSM/GPRS/EGPRS Rel’99
- Supported frequency:
- UMTS band 1/8
- EDGE/GPRS/GSM band 2/3/5/8
- DC-HSPA+ downlink data rate up to 42 Mbps
- HSUPA uplink data rate up to 5.76 Mbps
- UMTS data rate up to 384 kbps
- EDGE data rate up to 236.8 kbps
- GPRS data rate up to 85.6 kbps
IP65 Enclosures
Operating Environment
- Temperature: -40°C to 60°C (-40°F to 140°F)
- Humidity: 5% to 95% (Non-condensing)
Storage Environment
- Temperature: -40°C to 70°C (-40°F to 158°F)
- Humidity: 5% to 95% (Non-condensing)
Antennas
- 2 embedded antennas of up to 8 dBi
Power Specifications
- Standard 802.3 af power over Ethernet
- Power consumption at jack: < 10 W
* Supports to B1+B3 and B1+B7 are only available on LTE7460-M608-EU01V2F and LTE7460-M608-EU022F
