ZYXEL Wireless Access Point 802.11ac Wave 2 Dual Radio Unified Pro

0 értékelés

Gyártó: Zyxel
Cikkszám: WAC6303D-S-EU0101F
Készlet információ: Rendelésre
Átvétel: érkezés +1 munkanap

94 243 Ft

Bruttó ár: 119 689 Ft

Kívánságlistára

Összehasonlítás

Darab

Models

WAC6303D-S

802.11ac Wave 2 Dual-Radio Unified Pro Access Point

RF Specifications

802.11n/ac premium features

2.4GHz: 2x2 MIMO with two spatial stream (SU-MIMO)

5GHz: 3x3 MIMO with three spatial stream (SU-, or MU-MIMO)

802.11ac beamforming (transmit beamforming)

Maximal ratio combining (MRC)

Low End Sensitivity Improvements (LESI)

Time Domain Channel Smoothing

20-, 40- and 80-MHz channels

PHY data rates total up to 300 Mbps (11n) + 1300 Mbps (11ac)

Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

Cyclic Delay diversity (CSD) support

Maximum Likelihood Demodulation (MLD) support

Low Density Parity Check (LDPC) support

Typical transmit output power (dBm) ^*1

US (FCC) 2.4 GHz: 25 dBm

US (FCC) 5 G GHz: 28 dBm

EU (ETSI) 2.4 GHz: 20 dBm

EU (ETSI) 5 G GHz: 26 dBm

Antenna gain

2.4 GHz: 3 dBi; 2x2 MIMO

5 GHz: 4 dBi 3x3 MIMO

Support data rate

802.11a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps

802.11n: up to 300 Mbps in MCS15 (40MHz; 2 Spatial Streams; GI=400ns)

802.11ac:up to 1300 Mbps in MCS9 (80MHz; 3 Spatial Streams; GI=400ns)

Receive sensitivity Min. Rx sensitivity up to -103 dBm

Interfaces

Number of 10/100/1000M LAN 2 x switch ports

Console port 4-Pin serial

Input power requirements Direct DC power or Power over Ethernet (PoE)^*2

PoE 802.3at (full mode)
802.3af (Restrict 2.4G & 5G radio to one transmit stream only.)

PoE power draw 16.2W (802.3at PoE)

WLAN

WLAN maximum throughput Up to 1600 Mbps

Fast roaming Pre-authentication and PMK caching

Wireless Security

WPA/WPA2-PSK

WPA/WPA2-Enterprise

WLAN access control list

EAP type

IEEE 802.1X

MAC filtering

Web authentication ^*3

Layer-2 isolation

RADIUS authentication

Microsoft AD authentication^*3

LDAP authentication ^*3

MAC authentication ^*3

Rogue AP detection

Number of SSID 16

QoS

WMM

WMM power save

U-APSD

DiffServ marking

Network

IPv6 support Yes

VLANs Yes

DHCP client Yes

Management

ZON Utility^*4

Discovery of Zyxel switches, APs and gateways

Centralized and batch configurations

IP configuration

IP renew

Device factory reset

Device reboot

Device locating

Web GUI access

Firmware upgrade

Password configuration

One-click quick association with Zyxel AP Configurator (ZAC)

Smart Connect

Neighbor device discovery

One-click remote management access to the neighboring Zyxel devices

Zyxel AP Configurator^*5

Batch AP configuration

Batch AP firmware upgrade

Batch AP profile backup

Zyxel Wireless Optimizer ^*6

Wi-Fi AP planning

Wi-Fi coverage detection

Wireless health management

Standalone AP mode Yes

Managed AP mode Yes

CLI Yes

SNMP v2c/v3

Standard Compliance

Ethernet

IEEE 802.3

IEEE 802.3u

IEEE 802.11ab

IEEE 802.3au

IEEE 802.3az

IEEE 802.3af/at

PoE IEEE 802.3af/at

WLAN

802.11b: DBPSK, DQPSK, CCK

802.11g: BPSK, QPSK, 16-QAM, 64-QAM

802.11a: BPSK, QPSK, 16-QAM, 64-QAM

802.11n: BPSK, QPSK, 16-QAM, 64-QAM

802.11ac: BPSK, QPSK, 64-QAM, 256-QAM

Certifications

Radio

FCC Part 15C

FCC Part 15E

ETSI EN 300 328

EN 301 893

LP0002

EN 60601-1-2

EMC

FCC Part 15B

EN 301 489-1

EN 301 489-17

EN55032

EN55024

EN61000-3-2/-3

BSMI CNS13438

Safety

EN 60950-1

IEC 60950-1

BSMI CNS14336-1

Physical Specifications and others

Item Dimensions (WxDxH)(mm/in.)
211 x 223 x 39 / 8.31 x 8.78 x 1.54
Weight (kg/lb.)
800/1.76

Packing Dimensions (WxDxH)(mm/in.)
251 x 247 x 55 / 9.88 x 9.72 x 2.17
Weight (kg/lb.)
1040/ 2.29

Included accessories Wall/ceiling mount plate

Plenum rating Yes

Kensington lock support Yes

Power supply Input: AC 100-240V, 50~60Hz
Output: DC +12V 2A (Sold separately)

MTBF (hr) 3,960,217

Environmental Specifications

Operating Temperature
-20°C to 60°C / -4°F to 140°F
Humidity
10% to 90% (Non-condensing)

Storage Temperature
-40°C to 70°C / -40°F to 158°F
Humidity
10% to 90%

Specifikáció

Értékelések (0)

Írjon véleményt a termékről

Az Ön neve

Véleménye

Megjegyzés: HTML használata nem engedélyezett!

Értékelés Rossz Jó

Ellenőrző kód
Kérjük, adja meg az ellenőrző kódot

+361 340-0363

Kategóriák

Kategóriák

Kategóriák

ZYXEL Wireless Access Point 802.11ac Wave 2 Dual Radio Unified Pro

94 243 Ft

Specifikáció

Értékelések (0)

Írjon véleményt a termékről

Információk

Vevőszolgálat

Fiókom

Models	WAC6303D-S 802.11ac Wave 2 Dual-Radio Unified Pro Access Point
RF Specifications
802.11n/ac premium features	2.4GHz: 2x2 MIMO with two spatial stream (SU-MIMO) 5GHz: 3x3 MIMO with three spatial stream (SU-, or MU-MIMO) 802.11ac beamforming (transmit beamforming) Maximal ratio combining (MRC) Low End Sensitivity Improvements (LESI) Time Domain Channel Smoothing 20-, 40- and 80-MHz channels PHY data rates total up to 300 Mbps (11n) + 1300 Mbps (11ac) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) Cyclic Delay diversity (CSD) support Maximum Likelihood Demodulation (MLD) support Low Density Parity Check (LDPC) support
Typical transmit output power (dBm) ^*1	US (FCC) 2.4 GHz: 25 dBm US (FCC) 5 G GHz: 28 dBm EU (ETSI) 2.4 GHz: 20 dBm EU (ETSI) 5 G GHz: 26 dBm
Antenna gain	2.4 GHz: 3 dBi; 2x2 MIMO 5 GHz: 4 dBi 3x3 MIMO
Support data rate	802.11a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps 802.11n: up to 300 Mbps in MCS15 (40MHz; 2 Spatial Streams; GI=400ns) 802.11ac:up to 1300 Mbps in MCS9 (80MHz; 3 Spatial Streams; GI=400ns)
Receive sensitivity	Min. Rx sensitivity up to -103 dBm
Interfaces
Number of 10/100/1000M LAN	2 x switch ports
Console port	4-Pin serial
Input power requirements	Direct DC power or Power over Ethernet (PoE)^*2
PoE	802.3at (full mode) 802.3af (Restrict 2.4G & 5G radio to one transmit stream only.)
PoE power draw	16.2W (802.3at PoE)
WLAN
WLAN maximum throughput	Up to 1600 Mbps
Fast roaming	Pre-authentication and PMK caching
Wireless Security	WPA/WPA2-PSK WPA/WPA2-Enterprise WLAN access control list EAP type IEEE 802.1X MAC filtering Web authentication ^3 Layer-2 isolation RADIUS authentication Microsoft AD authentication^3 LDAP authentication ^3 MAC authentication ^3 Rogue AP detection
Number of SSID	16
QoS	WMM WMM power save U-APSD DiffServ marking
Network
IPv6 support	Yes
VLANs	Yes
DHCP client	Yes
Management
ZON Utility^*4	Discovery of Zyxel switches, APs and gateways Centralized and batch configurations IP configuration IP renew Device factory reset Device reboot Device locating Web GUI access Firmware upgrade Password configuration One-click quick association with Zyxel AP Configurator (ZAC)
Smart Connect	Neighbor device discovery One-click remote management access to the neighboring Zyxel devices
Zyxel AP Configurator^*5	Batch AP configuration Batch AP firmware upgrade Batch AP profile backup
Zyxel Wireless Optimizer ^*6	Wi-Fi AP planning Wi-Fi coverage detection Wireless health management
Standalone AP mode	Yes
Managed AP mode	Yes
CLI	Yes
SNMP	v2c/v3
Standard Compliance
Ethernet	IEEE 802.3 IEEE 802.3u IEEE 802.11ab IEEE 802.3au IEEE 802.3az IEEE 802.3af/at
PoE	IEEE 802.3af/at
WLAN	802.11b: DBPSK, DQPSK, CCK 802.11g: BPSK, QPSK, 16-QAM, 64-QAM 802.11a: BPSK, QPSK, 16-QAM, 64-QAM 802.11n: BPSK, QPSK, 16-QAM, 64-QAM 802.11ac: BPSK, QPSK, 64-QAM, 256-QAM
Certifications
Radio	FCC Part 15C FCC Part 15E ETSI EN 300 328 EN 301 893 LP0002 EN 60601-1-2
EMC	FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55024 EN61000-3-2/-3 BSMI CNS13438
Safety	EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Physical Specifications and others
Item	Dimensions (WxDxH)(mm/in.) 211 x 223 x 39 / 8.31 x 8.78 x 1.54 Weight (kg/lb.) 800/1.76
Packing	Dimensions (WxDxH)(mm/in.) 251 x 247 x 55 / 9.88 x 9.72 x 2.17 Weight (kg/lb.) 1040/ 2.29
Included accessories	Wall/ceiling mount plate
Plenum rating	Yes
Kensington lock support	Yes
Power supply	Input: AC 100-240V, 50~60Hz Output: DC +12V 2A (Sold separately)
MTBF (hr)	3,960,217
Environmental Specifications
Operating	Temperature -20°C to 60°C / -4°F to 140°F Humidity 10% to 90% (Non-condensing)
Storage	Temperature -40°C to 70°C / -40°F to 158°F Humidity 10% to 90%
