ZYXEL Wireless Access Point Wave2 Dual-Radio Unified 802.11ac

  • Gyártó: Zyxel
  • Cikkszám: NWA5123-ACHD-EU0101F
  • Készlet információ: Rendelésre
  • Átvétel: érkezés +1 munkanap

90 646 Ft

Bruttó ár: 115 120 Ft

Kívánságlistára
Összehasonlítás

Models
NWA5123-AC HD

802.11ac Wave2 Dual-Radio Unified Access Point

RF Specifications
802.11n/ac premium features
  • 802.11n: 2x2 MIMO with two spatial stream (SU-MIMO)
  • 802.11ac: 3x3 MIMO with three spatial stream (SU-, or MU-MIMO)
  • 802.11ac beamforming (transmit beamforming)
  • Maximal ratio combining (MRC)
  • Low End Sensitivity Improvements (LESI)
  • Time Domain Channel Smoothing
  • 20-, 40- and 80-MHz channels
  • PHY data rates total up to 300 Mbps (11n) + 1300 Mbps (11ac)
  • Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
  • Cyclic Delay diversity (CSD) support
  • Maximum Likelihood Demodulation (MLD) support
  • Low Density Parity Check (LDPC) support
Typical transmit output power (dBm) *1
  • US (FCC) 2.4 GHz: 25 dBm
  • US (FCC) 5 G GHz: 28 dBm
  • EU (ETSI) 2.4 GHz: 20 dBm
  • EU (ETSI) 5 G GHz: 26 dBm
Antenna gain
  • 2.4 GHz: 3 dBi; 2x2 MIMO
  • 5 GHz: 3 dBi 3x3 MIMO
Support data rate
  • 802.11a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
  • 802.11n: up to 300 Mbps in MCS15 (40MHz; 2 Spatial Streams; GI=400ns)
  • 802.11ac:up to 1300 Mbps in MCS9 (80MHz; 3 Spatial Streams; GI=400ns)
Receive sensitivity Min. Rx sensitivity up to -103 dBm
Interfaces
Number of 10/100/1000M LAN 2 x switch ports
Console port 4-Pin serial
Input power requirements Direct DC power or Power over Ethernet (PoE)*2
PoE 802.3at (full mode)
802.3af (Restrict 2.4G & 5G radio to one transmit stream only.)
PoE power draw 15.5 W (802.3at PoE)
WLAN
WLAN maximum throughput Up to 1600 Mbps
Fast roaming Pre-authentication and PMK caching
Wireless Security
  • WPA/WPA2-PSK
  • WPA/WPA2-Enterprise
  • WLAN access control list
  • EAP type
  • IEEE 802.1X
  • MAC filtering
  • Web authentication *3
  • Layer-2 isolation
  • RADIUS authentication
  • Microsoft AD authentication*3
  • LDAP authentication *3
  • MAC authentication *3
  • Rogue AP detection
Number of SSID 16
QoS
  • WMM
  • WMM power save
  • U-APSD
  • DiffServ marking
Network
IPv6 support Yes
VLANs Yes
DHCP client Yes
Management
ZON Utility*4
  • Discovery of Zyxel switches, APs and gateways
  • Centralized and batch configurations
    • IP configuration
    • IP renew
    • Device factory reset
    • Device reboot
    • Device locating
    • Web GUI access
    • Firmware upgrade
    • Password configuration
    • One-click quick association with Zyxel AP Configurator (ZAC)
Smart Connect
  • Neighbor device discovery
  • One-click remote management access to the neighboring Zyxel devices
Zyxel AP Configurator*5
  • Batch AP configuration
  • Batch AP firmware upgrade
  • Batch AP profile backup
Zyxel Wireless Optimizer *6
  • Wi-Fi AP planning
  • Wi-Fi coverage detection
  • Wireless health management
Standalone AP mode Yes
Managed AP mode Yes
CLI Yes
SNMP v2c/v3
Standard Compliance
Ethernet
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.11ab
  • IEEE 802.3au
  • IEEE 802.3az
  • IEEE 802.3af/at
PoE IEEE 802.3af/at
WLAN
  • 802.11b: DBPSK, DQPSK, CCK
  • 802.11g: BPSK, QPSK, 16-QAM, 64-QAM
  • 802.11a: BPSK, QPSK, 16-QAM, 64-QAM
  • 802.11n: BPSK, QPSK, 16-QAM, 64-QAM
  • 802.11ac: BPSK, QPSK, 64-QAM, 256-QAM
Certifications
Radio
  • FCC Part 15C
  • FCC Part 15E
  • ETSI EN 300 328
  • EN 301 893
  • LP0002
  • EN 60601-1-2
EMC
  • FCC Part 15B
  • EN 301 489-1
  • EN 301 489-17
  • EN55032
  • EN55024
  • EN61000-3-2/-3
  • BSMI CNS13438
Safety
  • EN 60950-1
  • IEC 60950-1
  • BSMI CNS14336-1
Physical Specifications and others
Item Dimensions (WxDxH)(mm/in.)
211 x 223 x 39 / 8.31 x 8.78 x 1.54
Weight (kg/lb.)
750/1.653
Packing Dimensions (WxDxH)(mm/in.)
251 x 247 x 55/9.88 x 9.72 x 2.17
Weight (kg/lb.)
990/2.182
Included accessories Wall/ceiling mount plate
Plenum rating Yes
Kensington lock support Yes
Power supply Input: AC 100-240V, 50~60Hz
Output: DC +12V 2A (Sold separately)
MTBF (hr) 4,134,738
Environmental Specifications
Operating Temperature
-20°C to 60°C / -4°F to 140°F
Humidity
10% to 90% (Non-condensing)
Storage Temperature
-40°C to 70°C / -40°F to 158°F
Humidity
10% to 90%
