ZYXEL Wireless NWA1123 AC HD Wave 2 Standalone / NebulaFlex AP 3x3 MU-MIMO Access Point (excludes Power Adaptor)

0 értékelés

Gyártó: Zyxel
Cikkszám: NWA1123-ACHD-EU0103F
Készlet információ: Rendelésre
Átvétel: érkezés +1 munkanap

52 512 Ft

Bruttó ár: 66 691 Ft

Kívánságlistára

Összehasonlítás

Darab

Models

NWA1123-AC HD

802.11ac Wave2 Dual-Radio PoE Access Point

RF Specifications

802.11n/ac premium features

2.4GHz: 2x2 MIMO with two spatial stream (SU-MIMO)

5GHz: 3x3 MIMO with three spatial stream (SU-, or MU-MIMO)

802.11ac beamforming (transmit beamforming)

Maximal ratio combining (MRC)

Low End Sensitivity Improvements (LESI)

Time Domain Channel Smoothing

20-, 40- and 80-MHz channels

PHY data rates total up to 300 Mbps (11n) + 1300 Mbps (11ac)

Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

Cyclic Delay diversity (CSD) support

Maximum Likelihood Demodulation (MLD) support

Low Density Parity Check (LDPC) support

Typical transmit output power (dBm) ^*1

US (FCC) 2.4 GHz: 25

US (FCC) 5 G GHz: 28

EU (ETSI) 2.4 GHz: 20

EU (ETSI) 5 G GHz: 26

Antenna gain

2.4 GHz: 3 dBi; 2x2 MIMO

5 GHz: 3 dBi 3x3 MIMO

Support data rate

802.11a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps

802.11n: up to 300 Mbps in MCS15 (40MHz; 2 Spatial Streams; GI=400ns)

802.11ac:up to 1300 Mbps in MCS9 (80MHz; 3 Spatial Streams; GI=400ns)

Receive sensitivity Min. Rx sensitivity up to -103 dBm

Interfaces

Number of 10/100/1000M LAN 2 x switch ports

Console port 4-Pin serial

Input power requirements Direct DC power or Power over Ethernet (PoE)^*2

PoE 802.3at (full mode)
802.3af (Restrict 2.4G & 5G radio to one transmit stream only.)

PoE power draw 15.5 W (802.3at PoE)

WLAN

WLAN maximum throughput Up to 900 Mbps

Fast roaming Pre-authentication and PMK caching

Wireless Security

WPA/WPA2-PSK

WPA/WPA2-Enterprise

WLAN access control list

EAP type

IEEE 802.1X

MAC filtering

Layer-2 isolation

RADIUS authentication^*6

Number of SSID 16

QoS

WMM

WMM power save

U-APSD

DiffServ Marking^*6

Network

IPv6 support Yes

VLANs Yes

DHCP client Yes

Management

ZON Utility^*3

Discovery of Zyxel switches, APs and gateways

Centralized and batch configurations

IP configuration

IP renew

Device factory reset

Device reboot

Device locating

Web GUI access

Firmware upgrade

Password configuration

One-click quick association with Zyxel AP Configurator (ZAC)

Smart Connect

Neighbor device discovery

One-click remote management access to the neighboring Zyxel devices

Zyxel AP Configurator^*4

Batch AP configuration

Batch AP firmware upgrade

Batch AP profile backup

Zyxel Wireless Optimizer^*5*6

WiFi AP planning

WiFi coverage detection

Wireless health management

Standalone AP mode Yes

CLI Yes

SNMP v2c/v3

Standard Compliance

Ethernet

IEEE 802.3

IEEE 802.3u

IEEE 802.11ab

IEEE 802.3au

IEEE 802.3az

IEEE 802.3af/at

PoE IEEE 802.3af/at

WLAN

802.11b: DBPSK, DQPSK, CCK

802.11g: BPSK, QPSK, 16-QAM, 64-QAM

802.11a: BPSK, QPSK, 16-QAM, 64-QAM

802.11n: BPSK, QPSK, 16-QAM, 64-QAM

802.11ac: BPSK, QPSK, 64-QAM, 256-QAM

Certifications

Radio

FCC Part 15C

FCC Part 15E

ETSI EN 300 328

EN 301 893

LP0002

EN 60601-1-2

EMC

FCC Part 15B

EN 301 489-1

EN 301 489-17

EN55032

EN55024

EN61000-3-2/-3

BSMI CNS13438

Safety

EN 60950-1

IEC 60950-1

BSMI CNS14336-1

Physical Specifications and others

Item Dimensions (WxDxH)(mm/in.)
211 x 223 x 39 / 8.31 x 8.78 x 1.54
Weight (kg/lb.)
750/1.65

Packing Dimensions (WxDxH)(mm/in.)
266 x 268 x 56/10.47 x 10.55 x 2.21
Weight (kg/lb.)
1090/2.40

Included accessories

Wall/ceiling mount plate

12V 2A adapter

Mounting screws

Plenum rating Yes

Kensington lock support Yes

Power supply Input: AC 100-240V, 50~60Hz
Output: DC +12V 2A (Sold separately)

MTBF (hr) 1,306,790

Environmental Specifications

Operating Temperature
-20°C to 50°C / -4°F to 122°F
Humidity
10% to 90% (Non-condensing)

Storage Temperature
-40°C to 70°C / -40°F to 158°F
Humidity
10% to 90%
