- Network Standard
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IPv4, IPv6
- Product Segment
N300 complete networking : 300 Mbps
- Coverage
Small homes
- Data Rate
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
- Connectivity Technology
LTE: Downlink 150 Mbps / Uplink 50 Mbps
- Antenna
External detachable 4dBi antenna x 2 for Mobile
Internal 3dBi antenna x 2 for Wi-Fi
- Transmit/Receive
MIMO technology
2.4 GHz 2 x 2
- Memory
512 MB Flash
256 MB RAM
- Operating Frequency
2.4 GHz
- Encryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPS support
- Firewall & Access Control
IP Filtering
MAC Filtering
URL Filtering
- Management
UPnP, DHCP, NTP Client, Port Trigger, Port Forwarding, DMZ, System Event Log
- WAN Connection Type
Mobile Broadband WAN
- Ports
RJ45 for 10/100 BaseT for LAN x 1
- Features
Traditional QoS
Guest Network : 1
- Button
WPS Button, Reset Button, Power Button
- LED Indicator
Power x 1
WAN x 1
3G/4G signal x 3
- Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1 A current
- OS Support
Windows® 10
Windows® 10 64-bit
Windows® 8.1
Windows® 8
Windows® 7
Windows® XP
Mac OS X 10.1
Mac OS X 10.4
Mac OS X 10.4
Mac OS X 10.5
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
Mac OS X 10.9 or Above
- Dimensions
110 x 67 x 114 mm (WxDxH)
- Weight
185 g
- Color
Black
- Package Content
-4G-N12 B1 Wi-Fi LTE router
-2 x detachable LTE antennas
-1 x RJ45 cable
-Quick Start Guide
-Power adapter
-Warranty card
- Note
E-UTRA(LTE) TDD: BAND 38
E-UTRA(LTE) FDD: BAND 1/3/7/8/20
W-CDMA FDD: BAND 1/8
